Frequency Range:
698MHz ~ 960MHz, 1.575GHz, 1.71GHz ~ 2.17GHz, 2.4GHz ~ 2.69GHz, 3.3GHz ~ 3.6GHz, 5.8GHz
HTSUS:
8529.10.9100
RoHS Status:
ROHS3 Compliant
Frequency Group:
Wide Band
Height (Max):
0.787" (20.00mm)
REACH Status:
REACH Unaffected
Applications:
Beidou, GLONASS, GPS, GNSS, GSM, LTE, UMTS, Wi-Fi
Gain:
28dBi
Number of Bands:
7
Package:
Box
Moisture Sensitivity Level (MSL):
1 (Unlimited)
RF Family/Standard:
Cellular, Navigation, WiFi
Frequency (Center/Band):
829MHz, 1.575GHz, 1.94GHz, 2.4GHz, 2.59GHz, 3.45GHz, 5.8GHz
Termination:
SMA Male
standardLeadTime:
11 Weeks
Ingress Protection:
IP67
Features:
Cable - 1m, LNA, Filter
Mounting Type:
Adhesive
Antenna Type:
Module
Series:
Guardian
VSWR:
3
Return Loss:
-10dB
Base Product Number:
MA931
ECCN:
7A994
