KOA CN Series 100kΩ ±5% Isolated Array Resistor, 8 Resistors 0805 package Concave SMT

CN2A8TTE104J KOA CN Series 100kΩ ±5% Isolated Array Resistor, 8 Resistors 0805 package Concave SMT
KOA

Product Information

Maximum Operating Temperature:
+155°C
Power Rating per Resistor:
0.1W
Circuit Designator:
ISOL
Number of Terminals:
16
Dimensions:
10.16 x 2 x 0.6mm
Series:
CN
Resistor Type:
Array
Termination Style:
Concave
Length:
10.16mm
Temperature Coefficient:
±200ppm/°C
Height:
0.6mm
Depth:
2mm
Number of Resistors:
8
Minimum Operating Temperature:
-55°C
Case Style:
Moulded
Package/Case:
0805 (2012M)
Tolerance:
±5%
Automotive Standard:
AEC-Q200
Resistance:
100kΩ
RoHs Compliant
Checking for live stock

This is CN Series 100kΩ ±5% Isolated Array Resistor 8 Resistors 0805 package Concave SMT manufactured by KOA. The manufacturer part number is CN2A8TTE104J. It has a maximum operating temperature of +155°c. It has a power rating of 0.1w per resistor . It has a/an isol designator circuit . It includes 16 dedicated terminals . The given dimensions of the product include 10.16 x 2 x 0.6mm. The product cn, is a highly preferred choice for users. The product is designed with a/an array type resistor . Moreover, it has concave terminal style. Its accurate length is 10.16mm. It exhibits an excellent temperature coefficient of ±200ppm/°c. In addition, the height is 0.6mm. The product comes in 2mm depth. It comprises 8 resistors. Whereas, the minimum operating temperature of the product is -55°c. Moreover, the casing is designed in moulded format and style. Concerning its package and casing, it is 0805 (2012m). It features ±5% of tolerance value. The product complies with automotive standard - aec-q200. It carries 100kω resistance.
