Contact Resistance:
50 mΩ
Dimensions:
60 x 15.8 x 18.5mm
Coil Voltage:
5V dc
Coil Resistance:
38Ω
Life:
1000000 (50 W) operations, 1000000000 (Dry) operations
Maximum Switching Voltage DC:
1000V
Maximum Switching Power DC:
50 W
Isolation Coil To Contact:
17kV
Maximum Operating Temperature:
+70°C
Terminal Type:
PCB Pin
Maximum Switching Current AC:
3 A
Operating Temperature Range:
-20 → +70°C
Contact Configuration:
SP-NC
Depth:
15.8mm
Relay Switching Classification:
General Purpose Relay
Special Features:
High Insulation Resistance, Low Contact Resistance
Mounting Type:
PCB Mount
Operating Time Including Bounce:
2ms
Length:
60mm
Height:
18.5mm
Maximum Switching Current DC:
3 A
Maximum Switching Voltage AC:
1000V
Minimum Operating Temperature:
-20°C
Number of Poles:
1
Contact Material:
Rhodium
This is PCB Mount Reed Relay 5V dc Coil SP-NC 1000V Max 3 A Max 38Ω manufactured by Sensata / Cynergy3. The manufacturer part number is DBR70510-HR/RS. It features a 50 mω contact resistance. The given dimensions of the product include 60 x 15.8 x 18.5mm. The coil voltage of the product is 5v dc. It holds up to 38ω coil resistance. It is capable of doing 1000000 (50 w) operations, 1000000000 (dry) operations in a lifetime . While it carries 1000v of maximum DC switching voltage. It bears a maximum 50 w of DC switching power. The product has 17kv isolation coil to contact. It has a maximum operating temperature of +70°c. The terminal is a pcb pin type. It has a maximum 3 a switching current AC . The product has -20 → +70°c of operating temperature range. The contact is equipped with sp-nc configuration. The product comes in 15.8mm depth. It has a general purpose relay switching relay configuration . The product also provides special features, such as high insulation resistance, low contact resistance. The product is available in pcb mount configuration. Moreover, the product offers a 2ms operating time including bounce . Its accurate length is 60mm. In addition, the height is 18.5mm. It has a minimum 3 a DC switching current . It has a maximum AC switching voltage of 1000v. Whereas, the minimum operating temperature of the product is -20°c. It has equipped with 1 poles. The product is made from sturdy rhodium materials.
