This is Cynergy3 PCB Mount Reed Relay 24V dc Coil SPST 2500V dc Max 3 A Max 780Ω manufactured by Sensata/Cynergy 3. The manufacturer part number is DAT200-24. It features a 600 mω contact resistance. The given dimensions of the product include 60 x 15.8 x 18.5mm. The coil voltage of the product is 24v dc. It holds up to 780ω coil resistance. It is capable of doing 1000000 (50 w) operations, 1000000000 (dry) operations in a lifetime . While it carries 2500v dc of maximum DC switching voltage. It bears a maximum 200 w of DC switching power. The product has 17kv isolation coil to contact. It has a maximum operating temperature of +70°c. The terminal is a pcb pin type. It has a maximum 3 a switching current AC . The product has -20 → +70°c of operating temperature range. The contact is equipped with spst configuration. The product comes in 15.8mm depth. The product is available in pcb mount configuration. Moreover, the product offers a 6ms operating time including bounce . Its accurate length is 60mm. In addition, the height is 18.5mm. It has a minimum 3 a DC switching current . It has a maximum AC switching voltage of 2500v ac. Whereas, the minimum operating temperature of the product is -20°c. The product is made from sturdy tungsten materials.
For more information please check the datasheets.
