Contact Resistance:
150 mΩ
Dimensions:
30 x 10 x 12mm
Coil Voltage:
12V dc
Coil Resistance:
750Ω
Life:
10000000 (100 W) operations, 1000000000 (Dry) operations
Standards Met:
cULus Recognised, UL Approved
Maximum Switching Voltage DC:
350V
Isolation Coil To Contact:
7kV
Maximum Operating Temperature:
+85°C
Terminal Type:
PCB Pin
Maximum Switching Current AC:
1 A
Operating Temperature Range:
-40 → +85°C
Contact Configuration:
SPST
Depth:
10mm
Relay Switching Classification:
General Purpose Relay
Special Features:
Space Saving
Mounting Type:
PCB Mount
Operating Time Including Bounce:
1ms
Length:
30mm
Height:
12mm
Maximum Switching Current DC:
1 A
Maximum Switching Voltage AC:
300V
Minimum Operating Temperature:
-40°C
Maximum Switching Power AC:
100VA
Number of Poles:
1
Contact Material:
Rhodium
