Contact Resistance:
30 mΩ
Dimensions:
27.6 x 7.3 x 8.5mm
Coil Voltage:
5V dc
Coil Resistance:
140Ω
Life:
100000000 (Electrical) cycles
Maximum Switching Voltage DC:
20V dc
Maximum Switching Power DC:
10 W
Isolation Coil To Contact:
3kV ac/dc
Maximum Operating Temperature:
+70°C
Terminal Type:
Through Hole
Maximum Switching Current AC:
0.5 A
Operating Temperature Range:
-20 → +70°C
Contact Configuration:
SPST
Depth:
7.3mm
Mounting Type:
PCB Mount
Operating Time Including Bounce:
1ms
Length:
27.6mm
Height:
8.5mm
Maximum Switching Current DC:
0.5 A
Maximum Switching Voltage AC:
20V ac
Minimum Operating Temperature:
-20°C
Contact Material:
Rhodium
HTSUS:
8536.41.0030
RoHS Status:
ROHS3 Compliant
Coil Voltage:
5VDC
Termination Style:
PC Pin
REACH Status:
REACH Unaffected
Operating Temperature:
-20°C ~ 70°C
Coil Resistance:
140 Ohms
Coil Current:
35.7 mA
Coil Type:
Non Latching
Switching Voltage:
20VAC, 20VDC - Max
Seal Rating:
-
edacadModel:
SAR90503 Models
edacadModelUrl:
/en/models/753350
Must Operate Voltage:
3.7 VDC
Package:
Tray
Contact Form:
SPST-NO (1 Form A)
Moisture Sensitivity Level (MSL):
1 (Unlimited)
Operate Time:
1 ms
Must Release Voltage:
0.5 VDC
standardLeadTime:
8 Weeks
Contact Rating (Current):
500 mA
Features:
-
Mounting Type:
Through Hole
Series:
S
Release Time:
0.5 ms
Contact Material:
Rhodium (Rh)
ECCN:
EAR99
