Contact Resistance:
600 mΩ
Dimensions:
60 x 15.8 x 18.5mm
Coil Voltage:
24V dc
Coil Resistance:
780Ω
Life:
1000000 (50 W) operations, 1000000000 (Dry) operations
Maximum Switching Voltage DC:
2500V dc
Maximum Switching Power DC:
200 W
Isolation Coil To Contact:
17kV
Maximum Operating Temperature:
+70°C
Terminal Type:
PCB Pin
Maximum Switching Current AC:
3 A
Operating Temperature Range:
-20 → +70°C
Contact Configuration:
SPST
Depth:
15.8mm
Mounting Type:
PCB Mount
Operating Time Including Bounce:
6ms
Length:
60mm
Height:
18.5mm
Maximum Switching Current DC:
3 A
Maximum Switching Voltage AC:
2500V ac
Minimum Operating Temperature:
-20°C
Contact Material:
Tungsten
HTSUS:
8536.41.0030
RoHS Status:
ROHS3 Compliant
Coil Voltage:
24VDC
Termination Style:
PC Pin
REACH Status:
REACH Unaffected
Operating Temperature:
-20°C ~ 70°C
Coil Current:
31 mA
Coil Type:
Non Latching
Switching Voltage:
2500VAC, 2500VDC - Max
Seal Rating:
-
edacadModel:
DAT200-24 Models
edacadModelUrl:
/en/models/4425824
Must Operate Voltage:
20 VDC
Manufacturer:
Sensata-Cynergy3
Contact Form:
SPST-NO (1 Form A)
Moisture Sensitivity Level (MSL):
1 (Unlimited)
Operate Time:
6 ms
Must Release Voltage:
4 VDC
standardLeadTime:
26 Weeks
Contact Rating (Current):
3 A
Features:
-
Mounting Type:
Through Hole
Series:
D200
Release Time:
1 ms
Packaging:
Bulk
ECCN:
EAR99
Base Product Number:
DAT200
Contact Material:
Tungsten (W)
