Contact Resistance:
80 mΩ
Dimensions:
30 x 10 x 11.5mm
Coil Voltage:
12V dc
Coil Resistance:
750Ω
Life:
10000000 (100 W) operations, 1000000000 (Dry) operations
Maximum Switching Voltage DC:
350V dc
Isolation Coil To Contact:
7kV
Maximum Operating Temperature:
+85°C
Terminal Type:
PCB Pin
Maximum Switching Current AC:
1 A
Operating Temperature Range:
-40 → +85°C
Contact Configuration:
SPST
Depth:
10mm
Mounting Type:
PCB Mount
Operating Time Including Bounce:
1ms
Length:
30mm
Height:
11.5mm
Maximum Switching Current DC:
1 A
Maximum Switching Voltage AC:
300V
Minimum Operating Temperature:
-40°C
Maximum Switching Power AC:
100VA
Contact Material:
Rhodium
HTSUS:
8536.41.0030
RoHS Status:
ROHS3 Compliant
Coil Voltage:
12VDC
Termination Style:
PC Pin
REACH Status:
REACH Unaffected
Operating Temperature:
-40°C ~ 85°C
Coil Resistance:
750 Ohms
Coil Current:
16 mA
Coil Type:
Non Latching
Switching Voltage:
300VAC, 350VDC - Max
Seal Rating:
-
edacadModel:
S8-1204 Models
edacadModelUrl:
/en/models/4425820
Must Operate Voltage:
9.6 VDC
Package:
Bulk
Contact Form:
SPST-NO (1 Form A)
Moisture Sensitivity Level (MSL):
1 (Unlimited)
Operate Time:
1 ms
Must Release Voltage:
2 VDC
standardLeadTime:
52 Weeks
Contact Rating (Current):
1 A
Features:
-
Mounting Type:
Through Hole
Series:
S8
Release Time:
0.5 ms
Contact Material:
Rhodium (Rh)
ECCN:
EAR99
