Contact Resistance:
250 mΩ
Dimensions:
60 x 15.8 x 18.5mm
Electrical Life:
10^6 (50W Switching) cycles, 10^9 (Dry Switching) cycles
Coil Resistance:
240Ω
Life:
10^6 (50W Switching) cycles, 10^9 (Dry Switching) cycles
Standards Met:
UL Approved
Maximum Switching Voltage DC:
3500V
Maximum Switching Power DC:
50 W
Isolation Coil To Contact:
17kV
Maximum Operating Temperature:
+70°C
Terminal Type:
PCB Pin
Maximum Switching Current AC:
2 A
Coil Voltage:
12V dc
Operating Temperature Range:
-20 → +70°C
Depth:
15.8mm
Relay Switching Classification:
General Purpose Relay
Special Features:
7.5kV or 5kV Isolation, Choice of 10kV, Excellent AC Characteristics, Low Contact Resistance, PCB or Panel mΩunt
Mounting Type:
PCB Mount
Operating Time Including Bounce:
2ms
Length:
60mm
Height:
18.5mm
Maximum Switching Current DC:
2 A
Maximum Switching Voltage AC:
3500V
Minimum Operating Temperature:
-20°C
Number of Poles:
1
Contact Material:
Tungsten
