Contact Resistance:
250 mΩ
Dimensions:
60 x 15.8 x 18.5mm
Coil Voltage:
5V dc
Coil Resistance:
28 Ω
Life:
1000000 (50 W) operations, 1000000000 (Dry) operations
Maximum Switching Voltage DC:
7000V
Maximum Switching Power DC:
50 W
Isolation Coil To Contact:
17kV
Maximum Operating Temperature:
+70°C
Terminal Type:
Flying Lead, PC Pin
Maximum Switching Current AC:
2 A
Operating Temperature Range:
-20 → +70°C
Contact Configuration:
SPNO
Depth:
15.8mm
Relay Switching Classification:
General Purpose Relay
Special Features:
High Insulation Resistance, Low Contact Resistance
Mounting Type:
PCB Mount
Operating Time Including Bounce:
3ms
Length:
60mm
Height:
18.5mm
Maximum Switching Current DC:
2 A
Maximum Switching Voltage AC:
7000V
Minimum Operating Temperature:
-20°C
Number of Poles:
1
Contact Material:
Tungsten
