Contact Resistance:
150 mΩ
Dimensions:
19.3 x 7 x 7.5mm
Coil Voltage:
5V dc
Coil Resistance:
200Ω
Life:
5000000 (Electrical)Cycles
Coil Power:
50mW
Maximum Switching Voltage DC:
175V dc
Maximum Switching Power DC:
3 W
Isolation Coil To Contact:
1.5kV rms
Maximum Operating Temperature:
+85°C
Terminal Type:
Through Hole
Operating Temperature Range:
-40 → +85°C
Contact Configuration:
SPDT
Depth:
7mm
Special Features:
High Vibration and Shock Resistance, Highly Reliable Switching
Mounting Type:
PCB Mount
Operating Time Including Bounce:
1.1ms
Length:
19.3mm
Height:
7.5mm
Maximum Switching Voltage AC:
175V ac
Minimum Operating Temperature:
-40°C
Maximum Switching Power AC:
3VA
Number of Poles:
1
Contact Material:
Ruthenium
Moisture Sensitivity Level (MSL):
Not Applicable
HTSUS:
8536.41.0050
Package:
Box
Series:
*
RoHS Status:
RoHS non-compliant
REACH Status:
REACH info available upon request
ECCN:
EAR99
