Contact Resistance:
100 mΩ
Dimensions:
24.1 x 6.2 x 8.1mm
Coil Voltage:
5V dc
Coil Resistance:
180 Ω
Life:
1000000000 (Dry) operations
Maximum Switching Voltage DC:
350V
Isolation Coil To Contact:
5kV dc
Maximum Operating Temperature:
+85°C
Terminal Type:
PCB Pin
Maximum Switching Current AC:
1 A
Operating Temperature Range:
-40 → +85°C
Contact Configuration:
SPNO
Depth:
6.2mm
Relay Switching Classification:
General Purpose Relay
Special Features:
Diode Fitted, Screened, Space Saving
Mounting Type:
PCB Mount
Operating Time Including Bounce:
1ms
Length:
24.1mm
Height:
8.1mm
Maximum Switching Current DC:
1 A
Maximum Switching Voltage AC:
300V
Minimum Operating Temperature:
-40°C
Maximum Switching Power AC:
100 VA
Number of Poles:
1
Contact Material:
Rhodium
