This is SPDT Reed Relay 5V manufactured by Littelfuse. The manufacturer part number is HE721C0510. It features a 200 mω contact resistance. The given dimensions of the product include 19.05 x 7.22 x 5.5mm. The coil voltage of the product is 5v dc. It holds up to 200 ω coil resistance. The product complies with all safety standards, such as culus e47258 recognized. While it carries 175v of maximum DC switching voltage. It bears a maximum 5 w of DC switching power. The product has 500v ac isolation coil to contact. It has a maximum operating temperature of +85°c. The terminal is a pcb pin type. The product has -40 → +85°c of operating temperature range. The contact is equipped with spdt configuration. Its accurate length is 19.05mm. The product also provides special features, such as diode suppression option, external magnetic shield option, optional coil suppression diode to protect coil drive circuits. The product is available in pcb mount configuration. Moreover, the product offers a 3ms operating time including bounce . The product comes in 7.22mm depth. In addition, the height is 5.5mm. It has a minimum 250 ma DC switching current . Whereas, the minimum operating temperature of the product is -40°c. It has equipped with 1 poles.
For more information please check the datasheets.
