Contact Resistance:
250 mΩ
Dimensions:
60 x 15.8 x 18.5mm
Electrical Life:
1000000 (50W Switching) cycles, 1000000000 (Dry Switching) cycles
Coil Resistance:
16Ω
Life:
100000000 (Electrical) cycles
Maximum Switching Voltage DC:
10000V dc
Maximum Switching Power DC:
50 W
Isolation Coil To Contact:
15kV ac/dc
Maximum Operating Temperature:
+70°C
Terminal Type:
Through Hole
Maximum Switching Current AC:
2 A
Coil Voltage:
5V dc
Operating Temperature Range:
-20 → +70°C
Contact Configuration:
SPST
Depth:
15.8mm
Relay Switching Classification:
General Purpose Relay
Mounting Type:
PCB Mount
Operating Time Including Bounce:
3ms
Length:
60mm
Height:
18.5mm
Maximum Switching Current DC:
2 A
Maximum Switching Voltage AC:
10000V ac
Minimum Operating Temperature:
-20°C
Contact Material:
Tungsten
