Vishay ESH1PD-M3/84A SMT Switching Diode, 200V 1A, 2-Pin SMP

ESH1PD-M3-84A Vishay ESH1PD-M3/84A SMT Switching Diode, 200V 1A, 2-Pin SMP
ESH1PD-M3/84A
ESH1PD-M3/84A
ET14079782
ET14079782
Rectifier Diodes & Schottky Diodes
Vishay

Product Information

Dimensions:
1.15 x 3.61 x 2.18mm
Rectifier Type:
Switching
Diode Configuration:
Single
Peak Reverse Recovery Time:
25ns
Maximum Continuous Forward Current:
1A
Package Type:
SMP
Number of Elements per Chip:
1
Maximum Operating Temperature:
+175 °C
Length:
3.61mm
Pin Count:
2
Width:
2.18mm
Mounting Type:
Surface Mount
Diode Technology:
Silicon Junction
Peak Non-Repetitive Forward Surge Current:
50A
Maximum Forward Voltage Drop:
900mV
Height:
1.15mm
Peak Reverse Current:
1µA
Peak Reverse Repetitive Voltage:
200V
Minimum Operating Temperature:
-55 °C
Diode Type:
Silicon Junction
RoHs Compliant
Checking for live stock

This is SMT Switching Diode 200V 1A 2-Pin SMP manufactured by Vishay. The manufacturer part number is ESH1PD-M3/84A. The given dimensions of the product include 1.15 x 3.61 x 2.18mm. This switching product is highly suited for various professionals in various settings. The diode features a single configuration. Moreover, it has a peak reverse recovery time about 25ns . Furthermore, its maximum continuous forward current constitutes 1a. The package is a sort of smp. It consists of 1 elements per chip. It has a maximum operating temperature of +175 °c. Its accurate length is 3.61mm. It contains 2 pins. Furthermore, the product is 2.18mm wide. The product is available in surface mount configuration. The product utilizes silicon junction diode technology. Moreover, a bespoke product has 50a peak non-repetitive forward surge current. It features 900mv of maximum forward voltage drop. In addition, the height is 1.15mm. It has a typical 1µa peak reverse current . While having the peak reverse repetitive 200v. Whereas, the minimum operating temperature of the product is -55 °c. It is designed with a silicon junction diode.
