Legend:
Blank
Push Button Style:
Round
Case Colour:
Silver
Contact AC Voltage Rating:
240V
Maximum AC Voltage:
24V
Illuminated:
Yes
Contact Current Rating:
3A
Voltage Rating:
240V
Manufacturer Part No.:
82-5551.1114
Maximum Operating Temperature:
+70°C
Terminal Type:
Plug In, Solder
Push Button Colour:
Silver
IP Rating:
IP65, IP67
LED Colour:
Red
Body Material:
Metal
Contact Configuration:
SPDT
Switch Operation:
Momentary
Maximum DC Voltage:
24V
Push Button Diameter:
19mm
Mounting Type:
Panel Mount
Series:
82
Contact DC Voltage Rating:
240V
Push Button Material:
Aluminium
Operating Temperature Range:
-30°C to +70°C
3D Model:
https://www.traceparts.com/els/rs-components/en/api/viewer/3d?SupplierID=RS_COMPONENTS&PartNumber=36070&DisplayLogo=False
Panel Cut Out Diameter:
19mm
Minimum Operating Temperature:
-30°C
Contact Material:
Silver Alloy
HTSUS:
8536.50.9031
RoHS Status:
ROHS3 Compliant
Electrical Life:
50,000 Cycles
Termination Style:
Solder, Quick Connect - 0.110" (2.8mm)
Voltage Rating - DC:
240 V
Operating Temperature:
-30°C ~ 70°C
Panel Cutout Dimensions:
Circular - 19.00mm Dia
Mechanical Life:
1,000,000 Cycles
Type:
Standard, Illuminated
Voltage Rating - AC:
240 V
REACH Status:
REACH Affected
Illumination Type, Color:
LED, Red
Package:
Bulk
Switch Function:
On-Mom
Moisture Sensitivity Level (MSL):
Not Applicable
Actuator Marking:
No Marking
Circuit:
SPDT
standardLeadTime:
14 Weeks
Current Rating (Amps):
3A (AC/DC)
Ingress Protection:
IP65/IP67 - Dust Tight, Water Resistant, Waterproof
Features:
-
Mounting Type:
Panel Mount, Front
Series:
82
Color - Actuator/Cap:
Silver
Actuator Type:
Round, Button, Flush
Illumination Voltage (Nominal):
24 VAC/DC
Base Product Number:
82-5551
ECCN:
EAR99
