SPNO PCB Mount Latching Relay 16 A, 3V dc

Enrgtech Part No: ET16826092
|
Manufacturer Part No:
ADW1103HLW
|
Manufacturer: Panasonic

ADW1103HLW SPNO PCB Mount Latching Relay 16 A, 3V dc

Product Information

Dimensions:

24 x 10 x 15.8mm

Coil Voltage:

3V dc

Application:

Home Appliances, Industrial Equipment, Lighting Control Equipment, Security Equipment, Smart Meters, Various Power Supplies

Terminal Type:

PCB Pin

Coil Resistance:

45Ω

Life:

Minimum of 1000000 (Mechanical) operations, Minimum of 20000 (Electrical) operations

Standards Met:

CSA, cUL, cULus, PTI 325V, TV-8, UL, VDE

Coil Power:

200mW

Isolation Coil To Contact:

5kVrms

Maximum Operating Temperature:

+70°C

Switching Current:

16A

Latching:

Yes

Checking for live stock

This is SPNO PCB Mount Latching Relay 16 A 3V dc manufactured by Panasonic. The manufacturer part number is ADW1103HLW. The given dimensions of the product include 24 x 10 x 15.8mm. The coil voltage of the product is 3v dc. Applications Information involves home appliances, industrial equipment, lighting control equipment, security equipment, smart meters, various power supplies. The terminal is a pcb pin type. It holds up to 45ω coil resistance. It is capable of doing minimum of 1000000 (mechanical) operations, minimum of 20000 (electrical) operations in a lifetime . The product complies with all safety standards, such as csa, cul, culus, pti 325v, tv-8, ul, vde. Robust coil power of 200mw. The product has 5kvrms isolation coil to contact. It has a maximum operating temperature of +70°c. It is integrated with 16a switching current. Latching Options - yes. The contact is equipped with spst configuration. The product comes in 10mm depth. The product is available in pcb mount configuration. Its accurate length is 24mm. In addition, the height is 15.8mm. It has a maximum AC switching voltage of 277v. Whereas, the minimum operating temperature of the product is -40°c. It also features an AC switching power of 4.432 kva. It has equipped with 1 poles. The product is made from sturdy silver alloy materials.
