Panasonic SPNO Non-Latching Relay PCB Mount, 24V dc Coil, 10 A Non-Latching Relay

Enrgtech Part No: ET16750228
|
Manufacturer Part No:
ALQ3F24
|
Manufacturer: Panasonic

ALQ3F24 Panasonic SPNO Non-Latching Relay PCB Mount, 24V dc Coil, 10 A Non-Latching Relay

Product Information

Coil Voltage:

24V dc

Application:

Air Conditioners, Cooking Ovens, Home Appliances, Industrial Equipment, Motor Controls, Power Supply, Refrigerators, Robots, Washing Machine

Terminal Type:

PCB Pin

Coil Resistance:

2880Ω

Life:

Minimum of 10000000 (Mechanical) operations

Standards Met:

CQC, CSA, cUL, cULus, UL, VDE

Coil Power:

200mW

Maximum Switching Voltage DC:

30V dc

Maximum Switching Power DC:

150 W

Isolation Coil To Contact:

4kVrms

Maximum Operating Temperature:

+85°C

Switching Current:

10A

Checking for live stock

This is SPNO Non-Latching Relay PCB Mount 24V dc Coil 10 A Non-Latching Relay manufactured by Panasonic. The manufacturer part number is ALQ3F24. The coil voltage of the product is 24v dc. Applications Information involves air conditioners, cooking ovens, home appliances, industrial equipment, motor controls, power supply, refrigerators, robots, washing machine. The terminal is a pcb pin type. It holds up to 2880ω coil resistance. It is capable of doing minimum of 10000000 (mechanical) operations in a lifetime . The product complies with all safety standards, such as cqc, csa, cul, culus, ul, vde. Robust coil power of 200mw. While it carries 30v dc of maximum DC switching voltage. It bears a maximum 150 w of DC switching power. The product has 4kvrms isolation coil to contact. It has a maximum operating temperature of +85°c. It is integrated with 10a switching current. Latching Options - no. The contact is equipped with spst configuration. The product comes in 10mm depth. The product is available in pcb mount configuration. Its accurate length is 20mm. In addition, the height is 15.6mm. It has a maximum AC switching voltage of 250v. Whereas, the minimum operating temperature of the product is -40°c. It also features an AC switching power of 1.25 kva. It has equipped with 1 poles. The product is made from sturdy silver alloy materials.
