Panasonic DPNO, SPNC Non-Latching Relay PCB Mount, 24V dc Coil, 1 A Non-Latching Relay

Enrgtech Part No: ET16750204
|
Manufacturer Part No:
AHES4292
|
Manufacturer: Panasonic

AHES4292 Panasonic DPNO, SPNC Non-Latching Relay PCB Mount, 24V dc Coil, 1 A Non-Latching Relay

Product Information

Coil Voltage:

24V dc

Application:

Industrial Equipment, Inverter, Office Air Conditioner, Photovoltaic Power Generation Systems, Uninterruptible Power Supplies

Terminal Type:

PCB Pin

Coil Resistance:

306.4Ω

Life:

Minimum of 100000 (Form B-Electrical) operations, Minimum of 50000 (Form A-Electrical) operations, Minimum of 5000000 (Mechanical) operations

Standards Met:

cUL, cULus, UL, VDE

Coil Power:

1.88W

Maximum Switching Voltage DC:

110V dc

Isolation Coil To Contact:

2000 (Form A) Vrms, 2000 (Form B) Vrms

Maximum Operating Temperature:

+85°C

Switching Current:

35A

Latching:

Checking for live stock

This is DPNO SPNC Non-Latching Relay PCB Mount 24V dc Coil 1 A Non-Latching Relay manufactured by Panasonic. The manufacturer part number is AHES4292. The coil voltage of the product is 24v dc. Applications Information involves industrial equipment, inverter, office air conditioner, photovoltaic power generation systems, uninterruptible power supplies. The terminal is a pcb pin type. It holds up to 306.4ω coil resistance. It is capable of doing minimum of 100000 (form b-electrical) operations, minimum of 50000 (form a-electrical) operations, minimum of 5000000 (mechanical) operations in a lifetime . The product complies with all safety standards, such as cul, culus, ul, vde. Robust coil power of 1.88w. While it carries 110v dc of maximum DC switching voltage. The product has 2000 (form a) vrms, 2000 (form b) vrms isolation coil to contact. It has a maximum operating temperature of +85°c. It is integrated with 35a switching current. Latching Options - no. The contact is equipped with dpst, spst configuration. The product comes in 36mm depth. The product is available in pcb mount configuration. Its accurate length is 30mm. In addition, the height is 40mm. It has a maximum AC switching voltage of 277 (form b) v, 480 (form a) v. Whereas, the minimum operating temperature of the product is -40°c. It also features an AC switching power of 277 (form b) va, 9695 (form a) va. It has equipped with 3 poles. The product is made from sturdy silver alloy materials.

Datasheet(Technical Reference)

Your Rating

Reviews

Be the first to review.

FAQs

Yes. You can also search AHES4292 on website for other similar products.

We accept all major payment methods for all products including ET16750204. Please check your shopping cart at the time of order.

You can order Panasonic brand products with AHES4292 directly through our website or call us at +44 (0) 3303 800 157 or email our support team at sales@enrgtech.co.uk.

Yes. Our products in Power Relays category are shipped in lowest possible time.

You will get a confirmation email regarding your order of Panasonic DPNO, SPNC Non-Latching Relay PCB Mount, 24V dc Coil, 1 A Non-Latching Relay. You can also check on our website or by contacting our customer support team for further order details on Panasonic DPNO, SPNC Non-Latching Relay PCB Mount, 24V dc Coil, 1 A Non-Latching Relay.

We use our internationally recognized delivery partners UPS/DHL. Collection of ET16750204 can also be arranged for the customer by international shipments through contacting our customer support team. Additionally, you can also search "Panasonic" products on our website by using Enrgtech's Unique Manufacturing Part Number ET16750204.

Yes. We ship AHES4292 Internationally to many countries around the world.
