Panasonic DPNO, SPNC Non-Latching Relay PCB Mount, 24V dc Coil, 1 A Non-Latching Relay

Enrgtech Part No: ET16750202
|
Manufacturer Part No:
AHES4192
|
Manufacturer: Panasonic

AHES4192 Panasonic DPNO, SPNC Non-Latching Relay PCB Mount, 24V dc Coil, 1 A Non-Latching Relay

Product Information

Coil Voltage:

24V dc

Application:

Industrial Equipment, Inverter, Office Air Conditioner, Photovoltaic Power Generation Systems, Uninterruptible Power Supplies

Terminal Type:

PCB Pin

Coil Resistance:

306.4Ω

Life:

Minimum of 100000 (Form B-Electrical) operations, Minimum of 30000 (Form A-Electrical) operations, Minimum of 5000000 (Mechanical) operations

Standards Met:

cUL, cULus, UL, VDE

Coil Power:

1.88W

Maximum Switching Voltage DC:

110V dc

Isolation Coil To Contact:

2000 (Form A) Vrms, 2000 (Form B) Vrms

Maximum Operating Temperature:

+85°C

Switching Current:

35A

Latching:

Checking for live stock

This is DPNO SPNC Non-Latching Relay PCB Mount 24V dc Coil 1 A Non-Latching Relay manufactured by Panasonic. The manufacturer part number is AHES4192. The coil voltage of the product is 24v dc. Applications Information involves industrial equipment, inverter, office air conditioner, photovoltaic power generation systems, uninterruptible power supplies. The terminal is a pcb pin type. It holds up to 306.4ω coil resistance. It is capable of doing minimum of 100000 (form b-electrical) operations, minimum of 30000 (form a-electrical) operations, minimum of 5000000 (mechanical) operations in a lifetime . The product complies with all safety standards, such as cul, culus, ul, vde. Robust coil power of 1.88w. While it carries 110v dc of maximum DC switching voltage. The product has 2000 (form a) vrms, 2000 (form b) vrms isolation coil to contact. It has a maximum operating temperature of +85°c. It is integrated with 35a switching current. Latching Options - no. The contact is equipped with dpst, spst configuration. The product comes in 36mm depth. The product is available in pcb mount configuration. Its accurate length is 30mm. In addition, the height is 40mm. It has a maximum AC switching voltage of 277 (form b) v, 480 (form a) v. Whereas, the minimum operating temperature of the product is -40°c. It also features an AC switching power of 277 (form b) va, 9695 (form a) va. It has equipped with 3 poles. The product is made from sturdy silver alloy materials.

Datasheet(Technical Reference)
