SPNO PCB Mount Latching Relay 16 A, 5V dc

Enrgtech Part No: ET16750164
|
Manufacturer Part No:
ADW1105HLW
|
Manufacturer: Panasonic

ADW1105HLW SPNO PCB Mount Latching Relay 16 A, 5V dc

Product Information

Dimensions:

24 x 10 x 15.8mm

Coil Voltage:

5V dc

Application:

Home Appliances, Industrial Equipment, Lighting Control Equipment, Security Equipment, Smart Meters, Various Power Supplies

Terminal Type:

PCB Pin

Coil Resistance:

125Ω

Life:

Minimum of 1000000 (Mechanical) operations, Minimum of 20000 (Electrical) operations

Standards Met:

CSA, cUL, cULus, PTI 325V, TV-8, UL, VDE

Coil Power:

200mW

Isolation Coil To Contact:

5kVrms

Maximum Operating Temperature:

+70°C

Switching Current:

16A

Latching:

Yes

Checking for live stock

This is SPNO PCB Mount Latching Relay 16 A 5V dc manufactured by Panasonic. The manufacturer part number is ADW1105HLW. The given dimensions of the product include 24 x 10 x 15.8mm. The coil voltage of the product is 5v dc. Applications Information involves home appliances, industrial equipment, lighting control equipment, security equipment, smart meters, various power supplies. The terminal is a pcb pin type. It holds up to 125ω coil resistance. It is capable of doing minimum of 1000000 (mechanical) operations, minimum of 20000 (electrical) operations in a lifetime . The product complies with all safety standards, such as csa, cul, culus, pti 325v, tv-8, ul, vde. Robust coil power of 200mw. The product has 5kvrms isolation coil to contact. It has a maximum operating temperature of +70°c. It is integrated with 16a switching current. Latching Options - yes. The contact is equipped with spst configuration. The product comes in 10mm depth. The product is available in pcb mount configuration. Its accurate length is 24mm. In addition, the height is 15.8mm. It has a maximum AC switching voltage of 277v. Whereas, the minimum operating temperature of the product is -40°c. It also features an AC switching power of 4.432 kva. It has equipped with 1 poles. The product is made from sturdy silver alloy materials.

Datasheet(Technical Reference)

Your Rating

Reviews

Be the first to review.

FAQs

Yes. You can also search ADW1105HLW on website for other similar products.

We accept all major payment methods for all products including ET16750164. Please check your shopping cart at the time of order.

You can order Panasonic brand products with ADW1105HLW directly through our website or call us at +44 (0) 3303 800 157 or email our support team at sales@enrgtech.co.uk.

Yes. Our products in Power Relays category are shipped in lowest possible time.

You will get a confirmation email regarding your order of SPNO PCB Mount Latching Relay 16 A, 5V dc. You can also check on our website or by contacting our customer support team for further order details on SPNO PCB Mount Latching Relay 16 A, 5V dc.

We use our internationally recognized delivery partners UPS/DHL. Collection of ET16750164 can also be arranged for the customer by international shipments through contacting our customer support team. Additionally, you can also search "Panasonic" products on our website by using Enrgtech's Unique Manufacturing Part Number ET16750164.

Yes. We ship ADW1105HLW Internationally to many countries around the world.
