Dimensions:
6.2 x 81 x 90mm
Coil Voltage:
24V dc
Terminal Type:
Push In
Coil Resistance:
100 mΩ
Life:
50000 (Electrical-NC) operations, 5000000 (Mechanical) operations, 70000 (Electrical-NO) operations
Standards Met:
CE, CULus, TUV Certification, UL 508 File No. E41643
Coil Power:
300mW
Maximum Switching Voltage DC:
125V dc
Maximum Switching Power DC:
180 W
Isolation Coil To Contact:
4kV ac
Maximum Operating Temperature:
+55°C
Switching Current:
6A
Maximum Switching Current AC:
6 A
Latching:
No
Contact Configuration:
SPDT
Depth:
81mm
Mounting Type:
DIN Rail
Series:
G2RV
Length:
6.2mm
Height:
90mm
Maximum Switching Current DC:
6 A
Maximum Switching Voltage AC:
440V ac
Minimum Operating Temperature:
-40°C
Maximum Switching Power AC:
1.5 kVA
Number of Poles:
1
Contact Material:
Silver Alloy
