Schneider Electric 3PDT Non-Latching Relay Plug In, 24V ac Coil, 12 A

750XCXH-24A Schneider Electric 3PDT Non-Latching Relay Plug In, 24V ac Coil, 12 A
Schneider Electric

Product Information

Mounting Type:
Plug In
Coil Power:
2W
Latching:
No
Coil Voltage:
24V ac
Length:
40.9mm
Height:
36.6mm
Switching Current:
12A
Application:
Automotive
Depth:
50.3mm
Maximum Switching Voltage AC:
300V
Maximum Switching Power DC:
500mW
Isolation Coil To Contact:
1.5kVrms
Contact Configuration:
3PDT
Number of Poles:
3
Terminal Type:
Plug In
Coil Resistance:
72Ω
RoHs Compliant
Checking for live stock

This is 3PDT Non-Latching Relay Plug In 24V ac Coil 12 A manufactured by Schneider Electric. The manufacturer part number is 750XCXH-24A. The product is available in plug in configuration. Robust coil power of 2w. Latching Options - no. The coil voltage of the product is 24v ac. Its accurate length is 40.9mm. In addition, the height is 36.6mm. It is integrated with 12a switching current. Applications Information involves automotive. The product comes in 50.3mm depth. It has a maximum AC switching voltage of 300v. It bears a maximum 500mw of DC switching power. The product has 1.5kvrms isolation coil to contact. The contact is equipped with 3pdt configuration. It has equipped with 3 poles. The terminal is a plug in type. It holds up to 72ω coil resistance.

pdf icon
Datasheet(Technical Reference)

Reviews

  • Be the first to review.

FAQs

Yes. You can also search 750XCXH-24A on website for other similar products.
We accept all major payment methods for all products including ET13864115. Please check your shopping cart at the time of order.
You can order Schneider Electric brand products with 750XCXH-24A directly through our website or call us at +44 (0) 3303 800 157 or email our support team at sales@enrgtech.co.uk.
Yes. Our products in Power Relays category are shipped in lowest possible time.
You will get a confirmation email regarding your order of Schneider Electric 3PDT Non-Latching Relay Plug In, 24V ac Coil, 12 A. You can also check on our website or by contacting our customer support team for further order details on Schneider Electric 3PDT Non-Latching Relay Plug In, 24V ac Coil, 12 A.
We use our internationally recognized delivery partners UPS/DHL. Collection of ET13864115 can also be arranged for the customer by international shipments through contacting our customer support team. Additionally, you can also search "Schneider Electric" products on our website by using Enrgtech's Unique Manufacturing Part Number ET13864115.
Yes. We ship 750XCXH-24A Internationally to many countries around the world.
