TE Connectivity SPDT Non-Latching Relay PCB Mount, 24V dc Coil, 12 A

5-1393239-5 TE Connectivity SPDT Non-Latching Relay PCB Mount, 24V dc Coil, 12 A
5-1393239-5
TE Connectivity

Product Information

Mounting Type:
PCB Mount
Coil Power:
400mW
Maximum Operating Temperature:
+85°C
Latching:
No
Coil Voltage:
24V dc
Length:
29mm
Height:
15.7mm
Switching Current:
12A
Application:
Power
Depth:
12.7mm
Maximum Switching Voltage AC:
400V ac
Minimum Operating Temperature:
-40°C
Maximum Switching Power AC:
3 kVA
Contact Configuration:
SPDT
Isolation Coil To Contact:
5kVrms
Contact Material:
Silver Alloy
Number of Poles:
1
Terminal Type:
Through Hole
Coil Resistance:
1440Ω
HTSUS:
8536.41.0060
Package:
Bulk
Series:
*
RoHS Status:
RoHS Compliant
ECCN:
EAR99
RoHs Compliant
Checking for live stock

This is SPDT Non-Latching Relay PCB Mount 24V dc Coil 12 A manufactured by TE Connectivity. The manufacturer part number is 5-1393239-5. The product is available in pcb mount configuration. Robust coil power of 400mw. It has a maximum operating temperature of +85°c. Latching Options - no. The coil voltage of the product is 24v dc. Its accurate length is 29mm. In addition, the height is 15.7mm. It is integrated with 12a switching current. Applications Information involves power. The product comes in 12.7mm depth. It has a maximum AC switching voltage of 400v ac. Whereas, the minimum operating temperature of the product is -40°c. It also features an AC switching power of 3 kva. The contact is equipped with spdt configuration. The product has 5kvrms isolation coil to contact. The product is made from sturdy silver alloy materials. It has equipped with 1 poles. The terminal is a through hole type. It holds up to 1440ω coil resistance. It is assigned with possible HTSUS value of 8536.41.0060. It is shipped in bulk package . The product is rohs compliant. The product is designated with the ear99 code number.
