Panasonic 4PDT Non-Latching Relay PCB Mount, 5V dc Coil, 10 A

SP4-P-DC5V Panasonic 4PDT Non-Latching Relay PCB Mount, 5V dc Coil, 10 A
Panasonic

Product Information

Life:
50000000 (Electrical) cycles
Minimum Operating Temperature:
-50°C
Mounting Type:
PCB Mount
Coil Power:
300mW
Maximum Operating Temperature:
+60°C
Latching:
No
Coil Voltage:
5V dc
Depth:
25.6mm
Height:
22mm
Switching Current:
10A
Application:
Power
Length:
51mm
Maximum Switching Power DC:
300 W
Maximum Switching Power AC:
2.5 kVA
Contact Configuration:
4PDT
Isolation Coil To Contact:
3kVrms
Contact Material:
Silver Alloy
Number of Poles:
4
Terminal Type:
Through Hole
Coil Resistance:
83Ω
RoHs Compliant
Checking for live stock

This is 4PDT Non-Latching Relay PCB Mount 5V dc Coil 10 A manufactured by Panasonic. The manufacturer part number is SP4-P-DC5V. It is capable of doing 50000000 (electrical) cycles in a lifetime . Whereas, the minimum operating temperature of the product is -50°c. The product is available in pcb mount configuration. Robust coil power of 300mw. It has a maximum operating temperature of +60°c. Latching Options - no. The coil voltage of the product is 5v dc. The product comes in 25.6mm depth. In addition, the height is 22mm. It is integrated with 10a switching current. Applications Information involves power. Its accurate length is 51mm. It bears a maximum 300 w of DC switching power. It also features an AC switching power of 2.5 kva. The contact is equipped with 4pdt configuration. The product has 3kvrms isolation coil to contact. The product is made from sturdy silver alloy materials. It has equipped with 4 poles. The terminal is a through hole type. It holds up to 83ω coil resistance.

pdf icon
SP Relay Data Sheet(Technical Reference)

Reviews

  • Be the first to review.

FAQs

Yes. You can also search SP4-P-DC5V on website for other similar products.
We accept all major payment methods for all products including ET13802449. Please check your shopping cart at the time of order.
You can order Panasonic brand products with SP4-P-DC5V directly through our website or call us at +44 (0) 3303 800 157 or email our support team at sales@enrgtech.co.uk.
Yes. Our products in Power Relays category are shipped in lowest possible time.
You will get a confirmation email regarding your order of Panasonic 4PDT Non-Latching Relay PCB Mount, 5V dc Coil, 10 A. You can also check on our website or by contacting our customer support team for further order details on Panasonic 4PDT Non-Latching Relay PCB Mount, 5V dc Coil, 10 A.
We use our internationally recognized delivery partners UPS/DHL. Collection of ET13802449 can also be arranged for the customer by international shipments through contacting our customer support team. Additionally, you can also search "Panasonic" products on our website by using Enrgtech's Unique Manufacturing Part Number ET13802449.
Yes. We ship SP4-P-DC5V Internationally to many countries around the world.
