Phoenix Contact 2903331

2903331 Phoenix Contact
2903331
2903331
ET12168814
ET12168814
Phoenix Contact

Product Information

The 2903331, a reliable, industry-grade solid-state relay terminal block from Phoenix Contact, designed for safe, efficient, and seamless electrical operations. Built with a compact and modular design, this high-geared relay offers versatile applications and ensures dependable automation in various industrial environments.

Dimensions:
96 x 75 x 16mm
Coil Voltage:
230V ac
Application:
Power
Terminal Type:
Plug In
Coil Resistance:
32500Ω
Life:
10000000 (Mechanical) cycles
Maximum Switching Voltage DC:
250V dc
Maximum Switching Power DC:
192 W
Maximum Operating Temperature:
+50°C
Switching Current:
8A
Latching:
No
Contact Configuration:
DPDT
Depth:
75mm
Mounting Type:
DIN Rail
Width:
16mm
Series:
RIF-1-RPT-LV-230AC/2X21
Length:
16mm
Height:
93mm
Maximum Switching Voltage AC:
250V ac
Minimum Operating Temperature:
-40°C
Maximum Switching Power AC:
2.5 kVA
Number of Poles:
2
Contact Material:
Silver Alloy
Must Release Voltage:
-
HTSUS:
8536.49.0050
RoHS Status:
ROHS3 Compliant
Coil Voltage:
230VAC
Termination Style:
Spring Terminal
REACH Status:
REACH Affected
Operating Temperature:
-40°C ~ 50°C
Approval Agency:
CSA
Coil Current:
6 mA
Coil Type:
Non Latching
Switching Voltage:
250VAC, 250VDC - Max
Seal Rating:
-
edacadModel:
2903331 Models
edacadModelUrl:
/en/models/4755350
Must Operate Voltage:
-
Relay Type:
General Purpose
Load - Max Switching:
-
Contact Form:
DPDT (2 Form C)
Moisture Sensitivity Level (MSL):
1 (Unlimited)
Operate Time:
12 ms
Qualification:
-
standardLeadTime:
8 Weeks
Contact Rating (Current):
8 A
Features:
Lighted Indicator, Socket Included, Varistor
Mounting Type:
DIN Rail
Grade:
-
Series:
RIF
Release Time:
20 ms
Packaging:
Bulk
Coil Insulation:
-
Contact Material:
Silver Nickel (AgNi)
Base Product Number:
29033
ECCN:
EAR99
RoHs Compliant
Checking for live stock

The Phoenix Contact 2903331 is a general-purpose double-pole double-throw (DPDT) relay designed to handle a current of up to 8A and operates at a voltage of 230V. It is a reliable and versatile relay commonly used in industrial control systems and automation applications. Its DPDT configuration, high current rating, and durable construction suit a wide range of industrial control and automation applications, including industrial automation, HVAC systems, lighting control, energy management, and process control.

Key Features of Phoenix Contact 2903331 Relay Include:

  • DPDT Configuration: The DPDT configuration of the relay allows it to control two separate circuits simultaneously, making it suitable for applications that require switching between two different loads.
  • High Current Rating: With a maximum current rating of 8A, the relay can handle moderate to high power loads, making it ideal for various industrial and commercial applications.
  • Reliable Operation: The Phoenix Contact 2903331 relay offers reliable performance, ensuring stable and consistent switching operations for extended periods.
  • Compact Design: The compact size of the relay enables easy installation and integration into control panels or equipment, optimizing space utilization.
  • Durable Construction: Built with high-quality materials, the relay is developed to handle harsh operating conditions, including temperature variations, humidity, and mechanical stress.

Where to Use the Phoenix Contact 2903331 Relay?

  • Industrial Automation: The relay is commonly used in industrial automation systems for controlling motors, solenoids, and other electrical devices.
  • HVAC Systems: It finds application in heating, ventilation, and air conditioning (HVAC) systems for controlling compressor motors, fan motors, and other components.
  • Lighting Control: The DPDT configuration makes it suitable for lighting control applications where switching between lighting circuits is required.
  • Energy Management: The relay can be used in energy management systems to control power distribution and switch between different power sources.
  • Process Control: In various industrial processes, the relay can control valves, pumps, and other equipment.

Additional Specifications of Phoenix Contact 2903331 Relay:

  • Contact Configuration: DPDT
  • Maximum Current Rating: 8A
  • Operating Voltage: 230V
  • Coil Voltage: Varies (depending on application requirements)
  • Mounting Type: Socket or PCB mounting
  • Mechanical Life: 10 million operations (minimum)
  • Operating Temperature Range: -40°C to +70°C

pdf icon
Line Drawing - 2903331(Technical Reference)
pdf icon
Application Note - 2903331(Technical Reference)
pdf icon
Datasheet 2903331(Technical Reference)
pdf icon
2903331(Datasheets)
