Panasonic Electric Works ADQM1604H

ADQM1604H Panasonic Electric Works
Panasonic Electric Works

Product Information

Must Release Voltage:
-
HTSUS:
8536.41.0050
RoHS Status:
RoHS Compliant
Coil Voltage:
4.5VDC
Termination Style:
PC Pin
Operating Temperature:
-40°C ~ 70°C
Approval Agency:
-
Coil Resistance:
40.5 Ohms
Coil Current:
111 mA
Coil Type:
Latching, Single Coil
Switching Voltage:
250VAC - Max
Seal Rating:
Sealed - Flux Protection
Must Operate Voltage:
3.6 VDC
Relay Type:
General Purpose
Load - Max Switching:
15000VA
Contact Form:
SPST-NO (1 Form A)
Moisture Sensitivity Level (MSL):
1 (Unlimited)
Operate Time:
20 ms
Qualification:
-
Contact Rating (Current):
60 A
Features:
-
Mounting Type:
Through Hole
Grade:
-
Series:
ADQM
Release Time:
20 ms
Packaging:
Tube
Coil Insulation:
-
Contact Material:
Silver Alloy, Cadmium Free
Base Product Number:
ADQM16
ECCN:
EAR99
Checking for live stock

This is manufactured by Panasonic Electric Works. The manufacturer part number is ADQM1604H. It is assigned with possible HTSUS value of 8536.41.0050. The product is rohs compliant. The coil voltage of the product is 4.5vdc. Moreover, it has pc pin terminal style. The product has -40°c ~ 70°c operating temperature range. It holds up to 40.5 ohms coil resistance. It has a coil current of 111 ma. The coil is a latching, single coil type. The product's switching voltage is 250vac - max. Seal rating options: sealed - flux protection. On the other hand, 3.6 vdc is the given crucial/must operating voltage. This is basically a general purpose. It also has a spst-no (1 form a) contact form. Its typical moisture sensitivity level is 1 (unlimited). The operating time of the product is 20 ms. It has a contact current rating of 60 a. The product is available in through hole configuration. The product adqm, is a highly preferred choice for users. While 20 ms is its release time. In addition, tube is the available packaging type of the product. The product is made from sturdy silver alloy, cadmium free materials. Moreover, it corresponds to adqm16, a base product number of the product. The product is designated with the ear99 code number.
