Actual Diameter:
0.098" (2.50mm ID), 0.217" (5.50mm OD)
HTSUS:
8536.69.4030
RoHS Status:
ROHS3 Compliant
Mounting Feature:
Bulkhead - Rear Side Nut
Thread Size:
M12x1
Operating Temperature:
-30°C ~ 180°C
Industry Recognized Mating Diameter:
2.50mm ID (0.098"), 5.50mm OD (0.217")
Internal Switch(s):
Single Switch, Normally Closed
Shielding:
Unshielded
Voltage - Rated:
48V
Insulation Color:
-
REACH Status:
REACH Unaffected
Includes:
3 pcs - 1 Connector, 1 Nut, 1 Washer
edacadModel:
54-00308 Models
Number of Positions/Contacts:
2 Conductors, 3 Contacts
Material Flammability Rating:
UL94 V-0
edacadModelUrl:
/en/models/17629568
Package:
Bulk
Gender:
Male
Connector Type:
Jack
Moisture Sensitivity Level (MSL):
1 (Unlimited)
Body Material:
-
Termination:
Solder
standardLeadTime:
14 Weeks
Current Rating (Amps):
8 A
Housing Material:
-
Body Color:
-
Ingress Protection:
IP67 - Dust Tight, Waterproof
Features:
Mounting Hardware, Thread Lock
Mounting Type:
Panel Mount
Mating Length/Depth:
-
Series:
-
Contact Material - Plating:
-
Contact Material:
-
ECCN:
EAR99
