Actual Diameter:
0.079" (2.00mm ID), 0.248" (6.30mm OD)
HTSUS:
8536.69.4040
RoHS Status:
ROHS3 Compliant
Mounting Feature:
-
Thread Size:
-
Operating Temperature:
-20°C ~ 70°C
Industry Recognized Mating Diameter:
2.05mm ID (0.081"), 5.50mm OD (0.217")
Internal Switch(s):
Single Switch, Normally Closed
Shielding:
Unshielded
Voltage - Rated:
20VDC
Insulation Color:
-
REACH Status:
REACH Unaffected
Includes:
-
edacadModel:
DCJ200-10-A-K1-K Models
Number of Positions/Contacts:
2 Conductors, 3 Contacts
Material Flammability Rating:
UL94 V-0
edacadModelUrl:
/en/models/9859579
Package:
Bulk
Gender:
Male
Connector Type:
Jack
Moisture Sensitivity Level (MSL):
Not Applicable
Body Material:
-
Termination:
Kinked Pin, Solder Eyelet
standardLeadTime:
6 Weeks
Current Rating (Amps):
5 A
Housing Material:
Polybutylene Terephthalate (PBT)
Body Color:
Black
Ingress Protection:
-
Features:
-
Mounting Type:
Through Hole, Right Angle
Mating Length/Depth:
-
Series:
DCJ200-10
Contact Material - Plating:
Silver
Contact Material:
Brass, Phosphor Bronze
Base Product Number:
DCJ200
ECCN:
EAR99
