Nippon Chemi-Con Aluminium Polymer Capacitor 680μF 20V dc 10mm JB5 PSG Series Polymer, Through Hole Polymer, ±20%

APSG200ELL681MJB5S Nippon Chemi-Con Aluminium Polymer Capacitor 680μF 20V dc 10mm JB5 PSG Series Polymer, Through Hole Polymer, ±20%
Nippon Chemi-Con

Product Information

Dimensions:
10 (Dia) x 11.5mm
Dissipation Factor:
0.12%
Capacitance:
680µF
Tolerance:
±20%
Dielectric Material Family:
Aluminium
Maximum Operating Temperature:
+105°C
Length:
11.5mm
Equivalent Series Resistance:
12mΩ
Leakage Current:
500 μA
Lead Pitch:
5mm
Polarised:
Polar
Diameter:
10mm
Ripple Current:
5400mArms
Mounting Type:
Through Hole
Series:
PSG
Height:
11.5mm
Voltage:
20V dc
Minimum Operating Temperature:
-55°C
Electrolyte Type:
Solid
Lifetime:
1000h
Technology:
Polymer
RoHs Compliant
Checking for live stock

This is Aluminium Polymer Capacitor 680μF 20V dc 10mm JB5 PSG Series Polymer Through Hole Polymer ±20% manufactured by Nippon Chemi-Con. The manufacturer part number is APSG200ELL681MJB5S. The given dimensions of the product include 10 (dia) x 11.5mm. It provides a dissipation factor of 0.12%. It provides a 680µf of capacitance value. It features ±20% of tolerance value. Whereas its dielectric material family is aluminium. It has a maximum operating temperature of +105°c. Its accurate length is 11.5mm. It has 12mω equivalent series resistance. It harbors 500 μa of leakage current. The lead features 5mm pitch. Furthermore, it is polar polarised. Its diameter is 10mm. Furthermore, 5400marms is the ripple current. The product is available in through hole configuration. The product psg, is a highly preferred choice for users. In addition, the height is 11.5mm. It carries a 20v dc of voltage. Whereas, the minimum operating temperature of the product is -55°c. It is a solid electrolyte. It provides a long-lasting service for a period of 1000h. This product use polymer technology.
