Broadcom HSMP-3816-TR1G Quad Complex Array PIN Diode, 1A, 100V, 5-Pin SOT-25

Enrgtech Part No: ET14154134
|
Manufacturer Part No:
HSMP-3816-TR1G
|
Manufacturer: Broadcom

HSMP-3816-TR1G Broadcom Quad Complex Array PIN Diode, 1A, 100V, 5-Pin SOT-25

Product Information

Maximum Diode Capacitance:

0.35pF

Dimensions:

3 x 1.7 x 1.3mm

Mounting Type:

Surface Mount

Application:

CATV/ Voltage Control Attenuator/ WCDMA

Typical Carrier Life Time:

1500ns

Maximum Forward Current:

Maximum Series Resistance @ Maximum IF:

3 Ω @ 100 mA

Height:

1.3mm

Width:

1.7mm

Length:

3mm

Package Type:

SOT-25

Number of Elements per Chip:

Checking for live stock

This is Quad Complex Array PIN Diode 1A 100V 5-Pin SOT-25 manufactured by Broadcom. The manufacturer part number is HSMP-3816-TR1G. It has a maximum 0.35pf diode capacitance . The given dimensions of the product include 3 x 1.7 x 1.3mm. The product is available in surface mount configuration. Applications Information involves catv/ voltage control attenuator/ wcdma. It has a standard 1500ns typical carrier life time . Moreover, the product has a maximum 1a forward current . It has a maximum 3 ω @ 100 ma series resistance @ maximum IF . In addition, the height is 1.3mm. Furthermore, the product is 1.7mm wide. Its accurate length is 3mm. The package is a sort of sot-25. It consists of 4 elements per chip. Moreover, the product has a maximum 100v reverse voltage . It has a maximum operating temperature of +150 °c. The diode features a complex array configuration. It contains 5 pins.

HSMP-3816-TR1G Data Sheet(Technical Reference)

ESD Control Selection Guide V1(Technical Reference)

Your Rating

Reviews

Be the first to review.

FAQs

Yes. You can also search HSMP-3816-TR1G on website for other similar products.

We accept all major payment methods for all products including ET14154134. Please check your shopping cart at the time of order.

You can order Broadcom brand products with HSMP-3816-TR1G directly through our website or call us at +44 (0) 3303 800 157 or email our support team at sales@enrgtech.co.uk.

Yes. Our products in PIN Diodes category are shipped in lowest possible time.

You will get a confirmation email regarding your order of Broadcom HSMP-3816-TR1G Quad Complex Array PIN Diode, 1A, 100V, 5-Pin SOT-25. You can also check on our website or by contacting our customer support team for further order details on Broadcom HSMP-3816-TR1G Quad Complex Array PIN Diode, 1A, 100V, 5-Pin SOT-25.

We use our internationally recognized delivery partners UPS/DHL. Collection of ET14154134 can also be arranged for the customer by international shipments through contacting our customer support team. Additionally, you can also search "Broadcom" products on our website by using Enrgtech's Unique Manufacturing Part Number ET14154134.

Yes. We ship HSMP-3816-TR1G Internationally to many countries around the world.
