Keysight Technologies, MSOX3014A Mixed Signal Oscilloscope, 4 Analogue. Ch., 16 Digital. Ch., 100MHz

Enrgtech Part No: ET14034776
|
Manufacturer Part No:
MSOX3014A
|
Manufacturer: Keysight Technologies

MSOX3014A Keysight Technologies, Mixed Signal Oscilloscope, 4 Analogue. Ch., 16 Digital. Ch., 100MHz

Product Information

Product Type:

Oscilloscope

Maximum Time Base:

50s/div

Power Source:

Mains

Minimum Time Base:

5ns/div

Series:

InfiniiVision 3000A X

Vertical Resolution:

8 bit

Height:

204mm

Width:

381 mm

Bandwidth:

100MHz

Number of Channels:

Interface Type:

USB

Minimum Vertical Sensitivity:

1mV/div

Checking for live stock

The Keysight Technologies MSOX3014A is a high-performance 100 MHz mixed-signal oscilloscope designed for advanced electronic debugging. It features four analogue and sixteen digital channels to provide a comprehensive view of complex designs. The 8.5-inch WVGA capacitive touch display offers an intuitive user interface for faster navigation. With an industry-leading update rate of 1 million waveforms per second, it easily captures infrequent glitches. This 6-in-1 digital oscilloscope integrates essential tools to maximise bench space and productivity.

Main Reasons to Use This Product

This Keysight Technologies MSOX3014A digital bench oscilloscope accelerates hardware debugging by combining multiple instruments into one robust unit. It identifies rare signal anomalies quickly using high-speed waveform update technology and touch-triggering capabilities.

Achieve precise measurements with uncompromised 1,000,000 wfms/s update rates.
Consolidate workflows via integrated protocol analysis and arbitrary waveform generation.

Special Features & Technical Specifications

Bandwidth: 100 MHz (Upgradable)
Channels: 4 Analog + 16 Digital
Sample Rate: Up to 4 GSa/s
Memory Depth: 2 Mpts standard (Upgradable to 4 Mpts)
Display: 8.5-inch capacitive touch screen
Instrument Integration: Oscilloscope, Logic Analyser, Protocol Analyzer, WaveGen, DVM, and Counter.

Datasheet(Technical Reference)

InfiniiVision 3000 X-Series Oscilloscopes Users Guide(Technical Reference)

Datasheet - 3000A X Series Oscilloscopes(Technical Reference)
