onsemi, FOD814S AC Input Phototransistor Output Dual Optocoupler, Surface Mount, 4-Pin MDIP

FOD814S onsemi,  AC Input Phototransistor Output Dual Optocoupler, Surface Mount, 4-Pin MDIP
FOD814S
onsemi

Product Information

Maximum Forward Voltage:
1.4V
Output Device:
Phototransistor
Isolation Voltage:
5 kVrms
Mounting Type:
Surface Mount
Series:
FOD
Typical Rise Time:
18µs
Maximum Current Transfer Ratio:
300%
Input Current Type:
AC
Number of Pins:
4
Number of Channels:
2
Package Type:
MDIP
Maximum Input Current:
50 mA
Typical Fall Time:
18µs
HTSUS:
8541.49.8000
RoHS Status:
ROHS3 Compliant
Current - Output / Channel:
50mA
Vce Saturation (Max):
200mV
Operating Temperature:
-55°C ~ 105°C
Input Type:
AC, DC
Package / Case:
4-SMD, Gull Wing
Current - DC Forward (If) (Max):
50 mA
Current Transfer Ratio (Min):
20% @ 1mA
Current Transfer Ratio (Max):
300% @ 1mA
Rise / Fall Time (Typ):
4µs, 3µs
REACH Status:
REACH Unaffected
Output Type:
Transistor
Number of Channels:
1
Voltage - Output (Max):
70V
Manufacturer:
onsemi
Moisture Sensitivity Level (MSL):
1 (Unlimited)
Voltage - Forward (Vf) (Typ):
1.2V
standardLeadTime:
15 Weeks
Voltage - Isolation:
5000Vrms
Mounting Type:
Surface Mount
Series:
-
Supplier Device Package:
4-SMD
Turn On / Turn Off Time (Typ):
-
Packaging:
Tube
Base Product Number:
FOD814
ECCN:
EAR99
RoHs Compliant
Checking for live stock

This is AC Input Phototransistor Output Dual Optocoupler Surface Mount 4-Pin MDIP manufactured by onsemi. The manufacturer part number is FOD814S. It also carries 1.4v of maximum forward voltage. Its output device includes phototransistor. It has 5 kvrms isolation voltage. The product is available in surface mount configuration. The product fod, is a highly preferred choice for users. It has a typical 18µs rise time . It has a maximum 300% current transfer ratio . Its input is of ac type . It is comprised of 4 pins. It is supplied with 2 channels. The package is a sort of mdip. While its maximum input current includes 50 ma. It has a typical 18µs fall time . It is assigned with possible HTSUS value of 8541.49.8000. The product is rohs3 compliant. It carries 50ma output or channel current. Feature a maximum Vce saturation of 200mv. The product has -55°c ~ 105°c operating temperature range. It carries ac, dc input type. Moreover, the product comes in 4-smd, gull wing. The maximum DC forward current of the product is 50 ma. It has a minimum current transfer ratio of 20% @ 1ma. Excellent efficiency with a maximum current transfer ratio of 300% @ 1ma. The typical rise and fall time of the product is 4µs, 3µs. In addition, it is reach unaffected. Furthermore, it has atransistor output. It is supplied with 1 channels. While the maximum output voltage is 70v. The onsemi's product offers user-desired applications. Its typical moisture sensitivity level is 1 (unlimited). The typical forward voltage (Vf) of the product is 1.2v. It has a long 15 weeks standard lead time. 5000vrms of isolation voltage. 4-smd is the supplier device package value. In addition, tube is the available packaging type of the product. Moreover, it corresponds to fod814, a base product number of the product. The product is designated with the ear99 code number.

pdf icon
FOD814 Series, FOD817 Series, 4-Pin High Operating Temperature Phototransistor Optocouplers Data Sheet(Technical Reference)
pdf icon
onsemi RoHS(Environmental Information)
pdf icon
onsemi REACH(Environmental Information)
pdf icon
FOD 11-3-22(PCN Assembly/Origin)
pdf icon
Mult Changes 11/Aug/2021(PCN Design/Specification)
pdf icon
Logo 17/Aug/2017(PCN Design/Specification)
pdf icon
FOD814, 817 Series(Datasheets)
pdf icon
Mult Devices 24/Oct/2017(PCN Packaging)
