Toshiba TLP5214(D4,E(O Photo IC Output Optocoupler, Surface Mount, 16-Pin SO-16L

TLP5214-D4-E-O Toshiba TLP5214(D4,E(O Photo IC Output Optocoupler, Surface Mount, 16-Pin SO-16L
Toshiba

Product Information

Maximum Forward Voltage:
1.8V
Output Device:
Photo IC
Isolation Voltage:
5000 Vrms
Mounting Type:
Surface Mount
Series:
TLP 5214
Typical Rise Time:
32ns
Number of Pins:
16
Number of Channels:
1
Package Type:
SO
Special Features:
AC And Brushless DC Motor Drives, Ideal for isolated IGBT/Power MOSFET Gate Drive, Industrial Inverters And Uninterruptible Power Supply, TLP5214 is Highly Integrated 40A Output Current IGBT Gate Drive Photo-Coupler Housed In Long Cree Page And Clearance
Maximum Input Current:
3.5 mA
Typical Fall Time:
18ns
RoHs Compliant
Checking for live stock

This is Photo IC Output Optocoupler Surface Mount 16-Pin SO-16L manufactured by Toshiba. The manufacturer part number is TLP5214(D4,E(O. It also carries 1.8v of maximum forward voltage. Its output device includes photo ic. It has 5000 vrms isolation voltage. The product is available in surface mount configuration. The product tlp 5214, is a highly preferred choice for users. It has a typical 32ns rise time . It is comprised of 16 pins. It is supplied with 1 channels. The package is a sort of so. The product also provides special features, such as ac and brushless dc motor drives, ideal for isolated igbt/power mosfet gate drive, industrial inverters and uninterruptible power supply, tlp5214 is highly integrated 40a output current igbt gate drive photo-coupler housed in long cree page and clearance. While its maximum input current includes 3.5 ma. It has a typical 18ns fall time .

pdf icon
TLP5214, Dual Photocoupler for IGBT Gate Drive with Desaturation Detection, Isolated Fault Status Feedback(Technical Reference)
pdf icon
Photocouplers and Photorelays(Technical Reference)
