Broadcom ACPL-847-W00E DC Input Phototransistor Output Quad Optocoupler, Through Hole, 16-Pin DIP

ACPL-847-W00E Broadcom DC Input Phototransistor Output Quad Optocoupler, Through Hole, 16-Pin DIP
Broadcom

Product Information

Maximum Forward Voltage:
1.4V
Output Device:
Phototransistor
Isolation Voltage:
5000 Vrms
Mounting Type:
Through Hole
Typical Rise Time:
4µs
Maximum Current Transfer Ratio:
600%
Input Current Type:
DC
Number of Pins:
16
Number of Channels:
4
Package Type:
DIP
Maximum Input Current:
5 mA
Typical Fall Time:
3µs
RoHs Compliant
Checking for live stock

This is DC Input Phototransistor Output Quad Optocoupler Through Hole 16-Pin DIP manufactured by Broadcom. The manufacturer part number is ACPL-847-W00E. It also carries 1.4v of maximum forward voltage. Its output device includes phototransistor. It has 5000 vrms isolation voltage. The product is available in through hole configuration. It has a typical 4µs rise time . It has a maximum 600% current transfer ratio . Its input is of dc type . It is comprised of 16 pins. It is supplied with 4 channels. The package is a sort of dip. While its maximum input current includes 5 ma. It has a typical 3µs fall time .

pdf icon
ACPL-8x7 Multi-Channel Full-Pitch Phototransistor Optocoupler Data Sheet(Technical Reference)
