Schneider Electric 4PDT Plug In Non-Latching Relay, 12V dc Coil, 3 A

782XDX3M4L-12D Schneider Electric 4PDT Plug In Non-Latching Relay, 12V dc Coil, 3 A
Schneider Electric

Product Information

Dimensions:
21 x 39.1 x 27.9mm
Coil Voltage:
12 V dc
Application:
General Purpose
Coil Resistance:
160 Ω
Life:
200000 (Electrical) Operations, 10000000 (Mechanical) Operations
Coil Power:
900mW
Maximum Switching Voltage DC:
30V
Maximum Switching Power DC:
500 mW
Isolation Coil To Contact:
1.6kV rms
Maximum Operating Temperature:
+55°C
Terminal Type:
Quick Connect
Maximum Switching Current AC:
3 A
Operating Temperature Range:
-40 → +55°C
Contact Configuration:
4PDT
Depth:
39.1mm
Mounting Type:
Plug In
Length:
21mm
Height:
27.9mm
Maximum Switching Current DC:
3 A
Maximum Switching Voltage AC:
300V
Minimum Operating Temperature:
-40°C
Contact Material:
Bifurcated
Checking for live stock

This is 4PDT Plug In Non-Latching Relay 12V dc Coil 3 A manufactured by Schneider Electric. The manufacturer part number is 782XDX3M4L-12D. The given dimensions of the product include 21 x 39.1 x 27.9mm. The coil voltage of the product is 12 v dc. Applications Information involves general purpose. It holds up to 160 ω coil resistance. It is capable of doing 200000 (electrical) operations, 10000000 (mechanical) operations in a lifetime . Robust coil power of 900mw. While it carries 30v of maximum DC switching voltage. It bears a maximum 500 mw of DC switching power. The product has 1.6kv rms isolation coil to contact. It has a maximum operating temperature of +55°c. The terminal is a quick connect type. It has a maximum 3 a switching current AC . The product has -40 → +55°c of operating temperature range. The contact is equipped with 4pdt configuration. The product comes in 39.1mm depth. The product is available in plug in configuration. Its accurate length is 21mm. In addition, the height is 27.9mm. It has a minimum 3 a DC switching current . It has a maximum AC switching voltage of 300v. Whereas, the minimum operating temperature of the product is -40°c. The product is made from sturdy bifurcated materials.
