Dimensions:
28 x 22.5 x 29mm
Coil Voltage:
110 V dc
Application:
Automation Control
Coil Resistance:
16.133 kΩ
Life:
100000 (Electrical) Operations, 30000000 (Mechanical) Operations
Standards Met:
CULus, LR, VDE
Coil Power:
750mW
Isolation Coil To Contact:
2.5kV rms
Maximum Operating Temperature:
+70°C
Terminal Type:
Plug In
Maximum Switching Current AC:
6 A
Operating Temperature Range:
-40 → +70°C
Contact Configuration:
4PDT
Depth:
22.5mm
Relay Switching Classification:
General Purpose Relay
Special Features:
Manual Test Tab, Mechanical Indicator, Optional Led And Protection Diode, Optionally Lockable, White Marking Tabs
Mounting Type:
Plug In
Length:
28mm
Height:
29mm
Maximum Switching Voltage AC:
240V
Minimum Operating Temperature:
-40°C
Maximum Switching Power AC:
1.5 kVA
Number of Poles:
4
Contact Material:
Silver Alloy
