Maxim MAX395CNG+, Analogue Switch Octal SPST, 3 V, 5 V, 9 V, 12 V, 15 V, 24-Pin PDIP

MAX395CNG- Maxim MAX395CNG+, Analogue Switch Octal SPST, 3 V, 5 V, 9 V, 12 V, 15 V, 24-Pin PDIP
MAX395CNG+
MAX395CNG+
ET14020242
ET14020242
Maxim

Product Information

Output Signal Type:
Single Ended
Dimensions:
32.13 x 7.87 x 4.45mm
Mounting Type:
Through Hole
Input Signal Type:
Single Ended
Power Supply Type:
Dual, Single
Maximum Power Dissipation:
1 W
Number of Channels per Chip:
8
Typical Dual Supply Voltage:
±5V
Height:
4.45mm
Typical Single Supply Voltage:
3 V, 5 V, 9 V, 12 V, 15 V
Width:
7.87mm
Length:
32.13mm
Package Type:
PDIP
Minimum Operating Temperature:
0 °C
Configuration:
Octal SPST
Maximum Operating Temperature:
+70 °C
Pin Count:
24
Switch Type:
Analogue
RoHs Compliant
Checking for live stock

This is Analogue Switch Octal SPST 3 V 5 V 9 V 12 V 15 V 24-Pin PDIP manufactured by Maxim. The manufacturer part number is MAX395CNG+. The output signal is a kind of single ended. The given dimensions of the product include 32.13 x 7.87 x 4.45mm. The product is available in through hole configuration. The input signal is a kind of single ended signal. It is a type of dual, single power supply. Provides up to 1 w maximum power dissipation. It comprises 8 channels per chip. While ±5v is the typical dual supply voltage. In addition, the height is 4.45mm. It has a typical single supply voltage of 3 v, 5 v, 9 v, 12 v, 15 v. Furthermore, the product is 7.87mm wide. Its accurate length is 32.13mm. The package is a sort of pdip. Whereas, the minimum operating temperature of the product is 0 °c. The product is available in octal spst configuration. It has a maximum operating temperature of +70 °c. It contains 24 pins. Quality product with a analogue switch type.

pdf icon
MAX395 Serially Controlled, Low-Voltage, 8-Channel SPST Switch Data Sheet(Technical Reference)
pdf icon
ESD Control Selection Guide V1(Technical Reference)
