Screened/Unscreened:
Unscreened
Standards Met:
CE Certified, DIN EN 50290-2-22, DIN VDE 0295 Class 5, EN 60228 Class 5, IEC 60332-1, IEC Certified, REACH EC 1907/2006
Control Cable Type:
YY
Voltage Rating:
300/500 V
Conductor Material:
Bare Copper
Maximum Operating Temperature:
(Dynamic) +70 °C, (Static) +80°C
Minimum Bend Radius:
10 x Cable Diameter (Dynamic), 4 x Diameter (Static)
Fire Behaviour:
Flame Retardant
Core Strands:
28/0.25 mm
Sheath Colour:
Grey
Length:
50m
Insulation Material:
PVC
Minimum Operating Temperature:
(Dynamic) -30 °C, (Static) -40°C
Number of Cores:
2
Conductor Resistance:
13.3 Ω/km @ 20°C
Cross Sectional Area:
1.5 mm²
Outer Diameter:
6.18mm
Sheath Material:
PVC
Ratings:
-
HTSUS:
8544.49.3080
RoHS Status:
ROHS3 Compliant
Jacket (Insulation) Material:
Poly-Vinyl Chloride (PVC)
Conductor Strand:
28/0.0098"
Operating Temperature:
-40°C ~ 80°C
Usage:
Industrial
Number of Conductors:
2
REACH Status:
REACH Unaffected
Package:
Spool
Wire Gauge:
15 AWG
Shield Type:
-
Jacket (Insulation) Thickness:
0.0287" (0.730mm)
Moisture Sensitivity Level (MSL):
1 (Unlimited)
Length:
164.0' (50.0m)
Conductor Insulation:
Poly-Vinyl Chloride (PVC)
standardLeadTime:
25 Weeks
Shield Coverage:
-
Features:
Chemical Resistant, Oil Resistant, UV Resistant
Jacket (Insulation) Diameter:
0.243" (6.17mm)
Conductor Material:
Copper, Bare
Series:
Pro-Met®
Cable Type:
Multi-Conductor
Voltage:
300 V
Shield Material:
-
ECCN:
EAR99
Base Product Number:
470215YY
Jacket Color:
Gray
