Name: NJM3717E2, New Japan Radio
Brand: New Japan Radio
SKU: ET14120002
Price: 1.43 GBP
Availability: Discontinued

NJM3717E2 New Japan Radio , Stepper Motor Driver IC, 40 V 0.35A 20-Pin, EMP

(0)

Product Information

Dimensions:

12.8 x 7.5 x 2.3mm

Mounting Type:

Surface Mount

Minimum Operating Supply Voltage:

4.75 V

Maximum Collector Emitter Voltage:

40 V

Maximum IGBT Collector Current:

0.35A

Height:

2.3mm

Width:

7.5mm

Length:

12.8mm

Package Type:

EMP

Minimum Operating Temperature:

-20 °C

Output Configuration:

Bipolar

Motor Type:

Stepper

Checking for live stock

This is Stepper Motor Driver IC 40 V 0.35A 20-Pin EMP manufactured by New Japan Radio. The manufacturer part number is NJM3717E2. The given dimensions of the product include 12.8 x 7.5 x 2.3mm. The product is available in surface mount configuration. While its minimum operating supply voltage is 4.75 v. Whereas features a 40 v of collector emitter voltage (max). It has a maximum 0.35a IGBT collector current . In addition, the height is 2.3mm. Furthermore, the product is 7.5mm wide. Its accurate length is 12.8mm. The package is a sort of emp. Whereas, the minimum operating temperature of the product is -20 °c. It boasts bipolar output configuration. This high-efficiency motor is a stepper. It has a maximum operating temperature of +125 °c. It contains 20 pins. It has 5.25 v maximum operating supply voltage.

ESD Control Selection Guide V1(Technical Reference)

NJM3717 STEPPER MOTOR DRIVER Data Sheet(Technical Reference)
