Infineon BTM7810K BLDC Motor Driver IC, 40 V 42A, 18-Pin PG-TO263

BTM7810K Infineon BLDC Motor Driver IC, 40 V 42A, 18-Pin PG-TO263
Infineon

Product Information

Automotive Standard:
AEC-Q100
Dimensions:
21.6 x 9.25 x 4.4mm
Mounting Type:
Surface Mount
Maximum Collector Emitter Voltage:
40 V
Maximum IGBT Collector Current:
42A
Height:
4.4mm
Width:
9.25mm
Length:
21.6mm
Package Type:
PG-TO263
Minimum Operating Temperature:
-40 °C
Output Configuration:
Full Bridge
Motor Type:
BLDC
Maximum Operating Temperature:
+110 °C
Pin Count:
18
Maximum Operating Supply Voltage:
42 V
Checking for live stock

This is BLDC Motor Driver IC 40 V 42A 18-Pin PG-TO263 manufactured by Infineon. The manufacturer part number is BTM7810K. The product complies with automotive standard - aec-q100. The given dimensions of the product include 21.6 x 9.25 x 4.4mm. The product is available in surface mount configuration. Whereas features a 40 v of collector emitter voltage (max). It has a maximum 42a IGBT collector current . In addition, the height is 4.4mm. Furthermore, the product is 9.25mm wide. Its accurate length is 21.6mm. The package is a sort of pg-to263. Whereas, the minimum operating temperature of the product is -40 °c. It boasts full bridge output configuration. This high-efficiency motor is a bldc. It has a maximum operating temperature of +110 °c. It contains 18 pins. It has 42 v maximum operating supply voltage.

pdf icon
BTM7810K TrilithIC(Technical Reference)
pdf icon
Efficient Semiconductor Solutions for Motor Control and Drives(Technical Reference)

Reviews

  • Be the first to review.

FAQs

Yes. You can also search BTM7810K on website for other similar products.
We accept all major payment methods for all products including ET13874568. Please check your shopping cart at the time of order.
You can order Infineon brand products with BTM7810K directly through our website or call us at +44 (0) 3303 800 157 or email our support team at sales@enrgtech.co.uk.
Yes. Our products in Motor Driver ICs category are shipped in lowest possible time.
You will get a confirmation email regarding your order of Infineon BTM7810K BLDC Motor Driver IC, 40 V 42A, 18-Pin PG-TO263. You can also check on our website or by contacting our customer support team for further order details on Infineon BTM7810K BLDC Motor Driver IC, 40 V 42A, 18-Pin PG-TO263.
