STMicroelectronics SCTH40N120G2V-7

SCTH40N120G2V-7 STMicroelectronics
STMicroelectronics

Product Information

Maximum Drain Source Voltage:
1200 V
Maximum Continuous Drain Current:
33 A
Mounting Type:
Surface Mount
Series:
SCTH40N
Maximum Drain Source Resistance:
0.105 O
Maximum Gate Threshold Voltage:
5V
Package Type:
H2PAK-7
Number of Elements per Chip:
1
Pin Count:
7
FET Feature:
-
HTSUS:
8541.29.0095
Vgs(th) (Max) @ Id:
4.9V @ 1mA
Operating Temperature:
-55°C ~ 175°C (TJ)
Rds On (Max) @ Id, Vgs:
100mOhm @ 20A, 18V
edacadModel:
SCTH40N120G2V-7 Models
Gate Charge (Qg) (Max) @ Vgs:
61 nC @ 18 V
RoHS Status:
ROHS3 Compliant
REACH Status:
REACH Unaffected
FET Type:
N-Channel
Drive Voltage (Max Rds On, Min Rds On):
18V
edacadModelUrl:
/en/models/13986410
Package:
Tape & Reel (TR)
Drain to Source Voltage (Vdss):
1200 V
Vgs (Max):
+22V, -10V
Moisture Sensitivity Level (MSL):
1 (Unlimited)
Power Dissipation (Max):
238W (Tc)
Input Capacitance (Ciss) (Max) @ Vds:
1233 pF @ 800 V
standardLeadTime:
52 Weeks
Mounting Type:
Surface Mount
Series:
-
Supplier Device Package:
H2PAK-7
Current - Continuous Drain (Id) @ 25°C:
36A (Tc)
Technology:
SiCFET (Silicon Carbide)
Base Product Number:
SCTH40
ECCN:
EAR99
RoHs Compliant
Checking for live stock

This is manufactured by STMicroelectronics. The manufacturer part number is SCTH40N120G2V-7. It has a maximum of 1200 v drain source voltage. While 33 a of maximum continuous drain current. The product is available in surface mount configuration. The product scth40n, is a highly preferred choice for users. It provides up to 0.105 o maximum drain source resistance. The product carries 5v of maximum gate threshold voltage. The package is a sort of h2pak-7. It consists of 1 elements per chip. It contains 7 pins. It is assigned with possible HTSUS value of 8541.29.0095. The typical Vgs (th) (max) of the product is 4.9v @ 1ma. The product has -55°c ~ 175°c (tj) operating temperature range. It has a maximum Rds On and voltage of 100mohm @ 20a, 18v. The maximum gate charge and given voltages include 61 nc @ 18 v. The product is rohs3 compliant. In addition, it is reach unaffected. It carries FET type n-channel. The drive voltage (maximum and minimum Rds On) of the product includes 18v. It is shipped in tape & reel (tr) package . The product has a 1200 v drain to source voltage. The maximum Vgs rate is +22v, -10v. Its typical moisture sensitivity level is 1 (unlimited). The product carries maximum power dissipation 238w (tc). The product's input capacitance at maximum includes 1233 pf @ 800 v. It has a long 52 weeks standard lead time. h2pak-7 is the supplier device package value. The continuous current drain at 25°C is 36a (tc). This product use sicfet (silicon carbide) technology. Moreover, it corresponds to scth40, a base product number of the product. The product is designated with the ear99 code number.
