Category:
Power MOSFET
Dimensions:
6.73 x 6.22 x 2.39mm
Maximum Continuous Drain Current:
42 A
Width:
6.22mm
Maximum Drain Source Voltage:
75 V
Maximum Gate Threshold Voltage:
4V
Maximum Drain Source Resistance:
26 mΩ
Package Type:
D2PAK (TO-263)
Number of Elements per Chip:
1
Minimum Gate Threshold Voltage:
2V
Maximum Operating Temperature:
+175 °C
Typical Gate Charge @ Vgs:
74 nC @ 10 V
Channel Type:
N
Typical Input Capacitance @ Vds:
2400 pF @ 25 V
Length:
6.73mm
Pin Count:
3
Forward Transconductance:
27S
Typical Turn-Off Delay Time:
65 ns
Mounting Type:
Surface Mount
Channel Mode:
Enhancement
Maximum Power Dissipation:
110 W
Series:
HEXFET
Maximum Gate Source Voltage:
-20 V, +20 V
Height:
2.39mm
Typical Turn-On Delay Time:
16 ns
Minimum Operating Temperature:
-55 °C
Forward Diode Voltage:
1.3V
