Category:
Power MOSFET
Dimensions:
1.7 x 1.7 x 0.8mm
Maximum Continuous Drain Current:
6 A
Transistor Material:
Si
Width:
1.7mm
Transistor Configuration:
Single
Maximum Drain Source Voltage:
30 V
Package Type:
SC-75
Number of Elements per Chip:
1
Minimum Gate Threshold Voltage:
1.2V
Maximum Operating Temperature:
+150 °C
Typical Gate Charge @ Vgs:
6.2 nC @ 10 V
Channel Type:
N
Typical Input Capacitance @ Vds:
350 pF @ 15 V
Length:
1.7mm
Pin Count:
6
Typical Turn-Off Delay Time:
13 ns
Mounting Type:
Surface Mount
Channel Mode:
Enhancement
Maximum Power Dissipation:
13 W
Maximum Gate Source Voltage:
-20 V, +20 V
Height:
0.8mm
Typical Turn-On Delay Time:
13 ns
Minimum Operating Temperature:
-55 °C
Maximum Drain Source Resistance:
50 mΩ
