Category:
Power MOSFET
Dimensions:
10.41 x 4.7 x 9.01mm
Maximum Continuous Drain Current:
75 A
Transistor Material:
Si
Width:
4.7mm
Transistor Configuration:
Single
Maximum Drain Source Voltage:
30 V
Package Type:
TO-220AB
Number of Elements per Chip:
1
Minimum Gate Threshold Voltage:
1V
Maximum Operating Temperature:
+175 °C
Typical Gate Charge @ Vgs:
160 nC @ 10 V
Channel Type:
P
Typical Input Capacitance @ Vds:
9000 pF@ 25 V
Length:
10.41mm
Pin Count:
3
Typical Turn-Off Delay Time:
150 ns
Mounting Type:
Through Hole
Channel Mode:
Enhancement
Maximum Power Dissipation:
3.75 W
Maximum Gate Source Voltage:
-20 V, +20 V
Height:
9.01mm
Typical Turn-On Delay Time:
25 ns
Minimum Operating Temperature:
-55 °C
Maximum Drain Source Resistance:
10 mΩ
