Category:
Power MOSFET
Dimensions:
15.87 x 5.31 x 20.82mm
Maximum Continuous Drain Current:
17 A
Transistor Material:
Si
Width:
5.31mm
Transistor Configuration:
Single
Maximum Drain Source Voltage:
600 V
Maximum Drain Source Resistance:
340 mΩ
Package Type:
TO-247AC
Number of Elements per Chip:
1
Minimum Gate Threshold Voltage:
3V
Maximum Operating Temperature:
+150 °C
Typical Gate Charge @ Vgs:
45.6 nC @ 10 V
Channel Type:
N
Typical Input Capacitance @ Vds:
1780 pF@ 10 V
Length:
15.87mm
Pin Count:
3
Typical Turn-Off Delay Time:
37 ns
Mounting Type:
Through Hole
Channel Mode:
Enhancement
Maximum Power Dissipation:
277.8 W
Series:
D Series
Maximum Gate Source Voltage:
-30 V, +30 V
Height:
20.82mm
Typical Turn-On Delay Time:
22 ns
Minimum Operating Temperature:
-55 °C
