Category:
Power MOSFET
Dimensions:
5 x 4 x 1.55mm
Maximum Continuous Drain Current:
21 A
Transistor Material:
Si
Width:
4mm
Transistor Configuration:
Single
Maximum Drain Source Voltage:
12 V
Maximum Drain Source Resistance:
7.4 mΩ
Package Type:
SOIC
Number of Elements per Chip:
1
Minimum Gate Threshold Voltage:
0.4V
Maximum Operating Temperature:
+150 °C
Typical Gate Charge @ Vgs:
52 nC @ 4.5 V
Channel Type:
N
Typical Input Capacitance @ Vds:
5020 pF @ 6 V
Length:
5mm
Pin Count:
8
Typical Turn-Off Delay Time:
85 ns
Mounting Type:
Surface Mount
Channel Mode:
Enhancement
Maximum Power Dissipation:
4.45 W
Maximum Gate Source Voltage:
-8 V, +8 V
Height:
1.55mm
Typical Turn-On Delay Time:
26 ns
Minimum Operating Temperature:
-55 °C
