Vishay IRFD320PBF N-channel MOSFET, 490 mA, 400 V, 4-Pin HVMDIP

IRFD320PBF Vishay N-channel MOSFET, 490 mA, 400 V, 4-Pin HVMDIP
Vishay

Product Information

Maximum Continuous Drain Current:
490 mA
Transistor Material:
Si
Width:
6.29mm
Transistor Configuration:
Single
Maximum Drain Source Voltage:
400 V
Maximum Drain Source Resistance:
1.8 Ω
Package Type:
HVMDIP
Number of Elements per Chip:
1
Minimum Gate Threshold Voltage:
2V
Maximum Operating Temperature:
+150 °C
Typical Gate Charge @ Vgs:
20 nC @ 10 V
Channel Type:
N
Length:
5mm
Pin Count:
4
Channel Mode:
Enhancement
Mounting Type:
Through Hole
Maximum Power Dissipation:
1 W
Maximum Gate Source Voltage:
-20 V, +20 V
Height:
3.37mm
Minimum Operating Temperature:
-55 °C
RoHs Compliant
Checking for live stock

This is N-channel MOSFET 490 mA 400 V 4-Pin HVMDIP manufactured by Vishay. The manufacturer part number is IRFD320PBF. While 490 ma of maximum continuous drain current. The transistor is manufactured from highly durable si material. Furthermore, the product is 6.29mm wide. The product offers single transistor configuration. It has a maximum of 400 v drain source voltage. It provides up to 1.8 ω maximum drain source resistance. The package is a sort of hvmdip. It consists of 1 elements per chip. Whereas its minimum gate threshold voltage includes 2v. It has a maximum operating temperature of +150 °c. With a typical gate charge at Vgs includes 20 nc @ 10 v. The product is available in [Cannel Type] channel. Its accurate length is 5mm. It contains 4 pins. The product carries enhancement channel mode. The product is available in through hole configuration. Provides up to 1 w maximum power dissipation. It features a maximum gate source voltage of -20 v, +20 v. In addition, the height is 3.37mm. Whereas, the minimum operating temperature of the product is -55 °c.
