Maximum Operating Temperature:
+60°C
Time Delay:
250 ms
Dimensions:
22.5 x 78 x 100 mm
Mounting Type:
DIN Rail
Operating Temperature Range:
-20 → +60 °C
Series:
EMR4
Monitoring Application:
Liquid Level
Height:
100mm
Width:
78mm
Length:
22.5mm
Supply Voltage:
220 → 240 V ac
Minimum Operating Temperature:
-20°C
Electrical Phase:
1
Contact Configuration:
SPDT
Number of Poles:
1
Terminal Type:
Screw
Standards Met:
CE Certified, CSA, CSA-22.2, EN 50022, EN 60255-6, EN 61000-4-5, EN 61000-4-6, IEC, IEC 1000-4-5, IEC 1000-4-6, IEC 255-5, IEC 255-6, IEC 60947-1, IEC 60947-5-1, IEC 664, IEC/EN 61000-4-2, IEC/EN 61000-4-3, IEC/EN 61000-4-4, U, UL, 2004/108/EC, 2006/95/EC
