Voltage Sensitivity:
Overvoltage, Undervoltage
Dimensions:
45 x 99.5 x 83.5 mm
Current Sensitivity:
Overcurrent, Undercurrent
Voltage Sensing Range:
-10 → +10 V dc, -1 → +1 V dc, 0.1 → 1 V ac/dc, 0.4 → 4 V ac, 1 → 10 V ac/dc
Width:
99.5mm
Supply Voltage:
115/230 V ac
Electrical Phase:
1
Maximum Current Sensed:
5 mA ac/dc, 5 mA dc, 20 mA ac/dc, 20 mA dc
Maximum Operating Temperature:
+60°C
Current Range:
-20 → +20 mA dc, -5 → +5 mA dc, 0.5 → 5 mA ac/dc, 2 → 20 mA ac/dc
Time Delay:
1 s, 6 s
Minimum Voltage Sensed:
-10 V dc, -1 V dc, 0.1 V ac/dc, 0.4 V ac, 1 V ac/dc
Operating Temperature Range:
-20 → +60 °C
Monitoring Application:
Current, Voltage
Maximum Voltage Sensed:
1 V ac/dc, 1 V dc, 4 V ac, 10 V ac/dc, 10 V dc
Minimum Current Sensed:
-20 mA dc, -5 mA dc, 0.5 mA ac/dc, 2 mA ac/dc
Length:
45mm
Contact Configuration:
DPDT
Height:
83.5mm
Minimum Operating Temperature:
-20°C
